PRODUCT STRUCTURE AND FEATURES
TY230S okuma turning center
UNIVERSAL MILLING MACHINE
Convincing arguments:quality,efficiency and price
●Versatile range of applications
●Rugged machine construction
●Smooth action due to polished gearwheels running in an oil sump
●Heavy,solid design using premium cast meehanite·All guides tempered and adjustable using cleats
●Central lubrication
●Generously dimensioned hand wheels with scales
●LED machine lamp
●Coolant system
●Easy operation of the switching elements
●Rugged,rectangular guide rails on Y and Z axis
●Table feed X,Y and Z axis automatic
●Digital position display DPA 21
●Feed system controllable by servomotor in fixed steps
●Decoupled hand wheels
●Solid and generously dimensioned cross table with precision surface finish including adjustable cleats and end stops
●Horizontal milling position
●Horizontal milling counterhotder,attached to rear of machine for easy access
●Milling head with two axes of rotation,thus pivots and rotates to any spatial angle
Type | TY230S |
Code No. | 2223000 |
Electrical data | |
Electrical connection | 380V 50Hz 3Ph |
Motor power horizontal | 5.5kw |
Motor power vertical | 4kw |
Motor coolant pump | 90w |
Milling head dimension max. | Φ160mm |
Spindle | |
Spindle seat | 7:24 ISO50 |
Throat | 260-910mm |
Draw-in rod | M24 |
Spindle speed horizontal | 60-1800rpm |
Gear stages/Steps horizontal | 12 |
Spindle speed vertical | 60-1750rpm |
Gear stages/Steps vertical | 12 |
Inclination of spindle head | 360° |
Cross table | |
Table length x table width | 1600×360mm |
Load of cross table (max.) | 400kg |
T-slot size / distance/count | 18mm/80mm/3 |
Distance horizontal spindle - table | 20-420mm |
Distance verticalspindle - table | 100-500mm |
Power Feed drive | 10Nm |
Travel X axis | 1300mm |
Travel Y axis | 300mm |
Travel Z axis | 400mm |
Drive speed feed/rapid motion | X:1200mm/min Y:800mm/min Z:600mm/min |
Feed speed | 30-750/20-500/15-375mm/min |
Dimensions | |
Length x width x height | 2520×2100×2000mm |
N.W./G.W. | 2800/2900kg |
Standard Accessories |
Operating tool |
Coolant equipment |
Machine lamp |
Digital position display DPA21 |
Chip tray |
Optional accessaries |
Machine vice |
Y/Z-Axis automatic feed |
58pcs Clamping fixture |
Milling chuck set J7325(8pcs/set) |
Milling chuck set J7325(15pcs/set) |
Workpiece support |
Mlill set |
